Hydraulic Parts

Our company provide SUNFLEX brand High pressure braided hose, high pressure spiral hose, produce and develop hose crimping joints, transition joints, stainless steel joints and all kinds of non-standard joints. Being widely used in Construction Machinery, tunnel construction machinery, special vehicle, oil, electric power, mine, metallurgy, shipbuilding,…etc.

Hydr

Industry search

应用

高压液体管道（液压油、防冻剂、空气和水）

技术参数

内层：耐油合成橡胶
增强层：二层高抗拉钢丝编织
外层：耐磨损、臭氧，合成橡胶,MSHA认证
温度范围：-40°F to +212°F（-40℃ to +100℃）
用于空气最高温度T=+70℃(+160°F )
应用标准：ISO 1436-1-SAE 100 R2AT/R2S,EN853 2SN

product details

软管代号 公称内径 软管尺寸 软管内径 软管外径 最大工作压力 最小爆破压力 最小弯曲半径 重量
PART NO. mm DASH inch mm mm MPa MPa mm g/m
R2T-04 6 -4 1/4" 6.6 14.9 40.0 160.0 80 365
R2T-05 8 -5 5/16" 8.1 16.6 35.0 140.0 90 435
R2T-06 10 -6 3/8" 10.0 18.7 33.0 132.0 100 535
R2T-08 12 -8 1/2" 13.0 21.7 27.5 110.0 100 630
R2T-10 16 -10 5/8" 15.9 25.0 25.0 100.0 120 740
R2T-12 19 -12 3/4" 19.0 21.9 21.5 86.0 140 920
R2T-16 25 -16 1" 25.4 37.9 16.5 66.0 180 1435
R2T-20 31 -20 1 1/4" 31.8 46.9 12.5 50.0 220 1915
R2T-24 38 -24 1 1/2" 38.1 53.9 9.0 36.0 260 2255
R2T-32 51 -32 2" 50.8 66.6 8.0 32.0 320 2960
R2T-40
 64 -40 2 1/2"
 63.5 79.8 6.9 30.0 760 3810
R2T-48 76 -48 3"
 76.2 91.9 5.0 24.0 900 4040
