Industrial Product

Our company design, research and develop hose,fittings and hose assembly, size DN6mm to DN 610mm with working pressure from 1 bar to 1000 bar, Applicable media include air, water, ethanol water, high temperature steam, Acid-base chemicals, food and beverage, cement slurry, concrete and various oil products, which widely used in construction Machinery, plastics machinery , Wind power, shipbuilding, petrochemical, iron and steel manufacturing and other heavy industries.

Indu

Industry search
技术参数

颜色：黑色
材料：合成橡胶
加强层：高强度棉线编织
外层：有条纹，耐摩擦
工作温度：-20℃到80℃
长度：30-60m（最长可至200米）

product details

产品型号 软管内径 厚度 重量 工作压力 爆破压力 拉力 弯曲半径
PART NO. mm inch mm g/m bar bar kg m
OF10-0125
 30 1-1/4 2 270 10 30 700 0.500
OF10-0150
 38 1-1/2 2
 310 10
 30
 900 0.700
OF10-0175
 45 1-3/4 2
 370 10
 30
 1.200 0.900
OF10-0200
 52 2 2
 450 10
 30
 1.300 1.100
OF10-0225
 60 2-1/4 2
 500 10
 30
 1.400 1.200
OF10-0250
 65 2-1/2 2
 620 10
 30
 1.400 1.300
OF10-0275
 70 2-3/4 2.5 650 10
 30
 1.700 1.350
OF10-0300
 76 3 2.5
 680 10
 30
 1.800 1.450
OF10-0325
 80 3-1/4 2.5
 700 10
 30
 1.850 1.450
OF10-0350
 90 3-1/2 2.5
 830 10
 30
 2.100 1.480
OF10-0400
 102 4 2.5
 950 10
 30
 2.400 1.700
OF10-0431
 110 - 3 1,100 10
 30
 4.000 1.800
OF10-0450
 115 4-1/2 3
 1,200 10
 30
 4.100 1.900
OF10-0500
 127 5 3
 1,450 10
 30
 4.200 2.100
OF10-0600
 152 6 3
 1,650 10
 30
 5.000 2.250
OF10-0800
 204 8 3
 2,250 10
 30
 6.600 3.000
OF10-1000
 254 10 3.5 2,800 8
 24 8.800 3.300
OF10-1200
 306 12 4 3,250 8
 24 10.200 3.600
