Our company design, research and develop hose,fittings and hose assembly, size DN6mm to DN 610mm with working pressure from 1 bar to 1000 bar, Applicable media include air, water, ethanol water, high temperature steam, Acid-base chemicals, food and beverage, cement slurry, concrete and various oil products, which widely used in construction Machinery, plastics machinery , Wind power, shipbuilding, petrochemical, iron and steel manufacturing and other heavy industries.

Indu

Industry search
技术参数

颜色：黄色
材料：合成橡胶
加强层：高强度棉线编织
外层：有条纹，耐摩擦
工作温度：-20℃到80℃
长度：30-60m（最长可至200米）

product details

产品型号 软管内径 厚度 重量 工作压力 爆破压力 拉力 弯曲半径
PART NO. mm inch mm g/m bar bar kg m
OF20-0075
 19 3/4 2.5 180 20 160 300 0.250
OF20-0075
 19 3/4 3.5 230 20
 160 300 0.250
OF20-0100
 27 1 3.5 235 20
 100 750 0.250
OF20-0100
 27 1 4 275 20 100 750 0.250
OF20-0150
 38 1-1/2 3.5 440 15
 75 1.200 0.650
OF20-0175
 45 1-3/4 3.5 520 15 75 1.400 0.750
OF20-0200
 52 2 3.5 650 10
 50
 1.500 1.200
OF20-0250
 65 2-1/2 4 750 10
 50
 2.050 1.250
OF20-0300
 76 3 4 950 10
 50
 2.600 1.300
OF20-0400
 102 4 4 1,275 10
 50
 3.780 1.700
OF20-0500
 127 5 4 1,800 10
 50
 5.980 1.970
OF20-0600
 152 6 4 2,100 10
 50
 7.280 1.970
OF20-0800
 204 8 4.5 2,550 10
 50
 9.320 2.250
